Based on capacitive sensing and 360° holistic scanning, an effective approach compensating eccentricity error and offering better noise cancellation comparing to optical or magnetic sensing, the CAPRO-B series demonstrate comprehensive advantages on cost-effectiveness, good accuracy and robustness for various applications.
-B stands for that the products are housed with integral bearings.
Specification
Resolution
16-23 bits
Repeatability
5 arc seconds
Accuray
±50 arc seconds; or ±5arc seconds(with calibration and compensation)
Multi turn
16 bits, customizable
Power supply
5-24 VDC
Current
150mA@5VDC
Interface
SSI，BISS C，RS485，RS485+AB，TTL
Speed
3,500RPM
W/ temperature
-40...+85°C
Humidity
<98%, no condensation
For installation of CAPRO-B encoders, spring coupler is applied to fixed the housing on the flange and a clamping ring locks the central hole with the targeted shaft. The mechanical parameters (as indicated in the figure) of various models are listed in the following table.
Model
5013
6020
7625
11054
ID(mm)
11
19
24
50
OD(mm)
52
62
78
112
H(mm)
35
37
32
49
Please click on the QR code below to download the detailed product data parameters:
