Gear magnetic encoder GAME
wMagnetic sensor scans the varied magnetic field caused by the rotating gear wheel
wOuput 1 Vpp Differential signal (sin/cos) or TTL / RS422
wHigh signal quality and low speed ripple
wMaintenance and wear-free
wHarsh environment of high moisture, condensation, oil, vibration
wCustomized production of precision target wheels enables flexible integration into applications
Electrical data:
Specs
GAME-T (TTL)
GAME-A (sin/cos)
Supply power
5 VDC±10%
Output signal
RS422 (TTL)
Sin/Cos 1Vpp
Output current
≤27 mA
≤20 mA
Signal ripple
50%±10%
1Vpp±5%
Phase error
90°±10%
90°±5%
Input frequency
≤500 kHz
≤500kHz
Output frequency
≤8 MHz
Interpolation
2n(Customizable)
NA
EMC
EN 61000-6-2 \ EN 61000-6-3
Mechanical data:
Tooth module
0.4 to 1.0
Z track form
Removed tooth or single tooth
Air gap between sensor and wheel
0.2mm(0.4 module), 0.3mm(0.5 module), 0.5mm(0.8 module)
Air gap error
±0.05 mm
Sensor housing
Al alloy
Gear material
Ferromagnetic stee
Gear precision grade
7 or above
Working temperature
-30 °C ~ 85°C
Degree of protection
IP68
Vibration resistance
200m/s2, DIN EN 60068-2-6
Shock resistance
2000m/s2, 60068-2-27
Please click on the QR code below to download the detailed product data parameters:
